CP-PC180-AV - Anti Vandal Adjustable Lens Thru-Beam Photocell

CP-PC180-AV - Anti Vandal Adjustable Lens Thru-Beam Photocell


The CP-PC180-AV is an anti-vandal infrared photocell with die-cast aluminum casing, anti-vandal


The optical system of both the transmitter and receiver can be rotated up to 180° which allows side aiming, therefore the units do not have to be mounted face-to-face and the beam direction cannot be discerned by simple observation.


They are ideal for safety use on gates, roller shutters and garage doors. Detecting obstacles including vehicles and people, when the beam is broken the equipment will stop and reverse, preventing damage or injury.


Can also be used to activate alarms, lighting and other devices.

  • Details


    • Adjustable optics 180 ° horizontally and 30 ° vertically
    • Very sturdy and durable for intensive use
    • Power supply: 12V dc - 24V ac / dc
    • Range: 20 m
    • Double rubber seal
    • Double hole for cable entry
    • Degree of protection: IP55
    • Compliant with EN12453, EN954, RoHS
    • Dimensions: 100x45x45 mm
    • Weight: 460g per pair
    • High immunity against noise generated by brushless motors and inverters
